# Write yourself a toolchain using LLVM

##### Francis Visoiu Mistrih - <francis@lse.epita.fr>

---

# Goal

#### C file

```c
int foo(int);
int bar(int a)
{
  return foo(a);
}
```

#### J Core machine code

```asm
0x100:	e2 2f 	mov.l	r14, @r15
0x102:	e3 6f 	mov	  r15, r14
0x104:	f0 7f 	add	  #-16, r15
[...]
0x10c:	0b 40 	jsr	  @r0
0x10e:	09 00 	nop
[...]
0x118:	0b 00 	rts
0x11a:	09 00 	nop
```

---

# Goal

#### NOT write a compiler from scratch

#### Don't reimplement smart and optimized algorithms

#### Instead, discover them

#### And discover other targets

### Understand compiler internals

---

# LLVM

#### Collection of libraries

#### Releases libraries

#### Expose APIs to every stage of the compiler

#### Rarely care about backward compatibility

---

# Toolchain

### Compilation - cc1

### Assembly - as

### Linking - ld

### Runtime - builtins / libc

---

# Compilation

### Lexing

### Parsing

### Semantic analysis

### Intermediate representation

### IR optimizations

### Instruction selection

### Register allocation

---

# Assembly

### Parsing

### Encoding

# Linking

### Collect object files

### Generate sections (.plt, .dynamic, ...)

### Merge sections

### Fix relocations

---

# Runtime

### Builtins

### libc

### Sanitizers

---

# The LLVM Compiler Infrastructure

### LLVM Core

### Clang

### LLD

### LLDB

#### libc++

#### compiler-rt

---
class: middle, center, inverse

# Let's add our target!

#### Clang -> LLVM -> LLD

---

# Clang

#### Clang generates LLVM IR from C / C++ / Objective-C

#### Lowers front end constructions to lower-level ones

---
class: top, center, inverse

## Clang

Target informations:

```center
Pointer width, pointer align, size_t / ptrdirr_t types, endianness, etc.
```

##### cpp integrated in the front end

CPP defines:

```center
__TARGET__, __ELF_, __APPLE__, __x86__, etc.
```

---
class: top, center, inverse

## LLVM Core

#### Registers:

```center
registers, callee saved, caller saved, fp, sp, reserved, etc.
```

###### Integrated assembler

#### Instructions:

```center
opcode, encoding, in / out regs, IR pattern, string, isBranch, sideEffects, etc.
```

#### Calling conventions:

```center
argument passing, result value, stack alignment, argument types, etc.
```

#### Relocations:

```center
symbols, relocation generation, ELF definitions, etc.
```

---
class: top, center, inverse

## LLD

### We generate relocations in the back end

### We need to fix them in the linker

#### ELF:

```center
ELF arch, target info, etc.
```

#### Relocations:

```center
relocation type, position independent, relocation action, relocation name, etc.
```

---

# J-Core

### SH2 ISA

### Hitachi SuperH - Sega Saturn

### Different models: SH2 <-> J2, SH3 <-> J3, etc.

### ARM Thumb's inspiration

### Open source

### VHDL implementation

---
class: top, center, inverse

# J2

### 5-stage RISC

### 16-bit instructions

#### 133 instructions

### 32-bit registers

#### 16 general purpose registers

#### 1 64-bit register

---

# How to start

#### Add the target to LLVM / Clang / LLD

##### Unlike GCC, you don't need to build a cross-compiler

##### Describe your target and the subtargets

---

# Registers

```tablegen
def R0 : J2Reg<0, "r0">, DwarfRegNum<[ 0 ]>;

[...]

def R15 : J2Reg<15, "r15", [ "sp" ]>, DwarfRegNum<[ 15 ]>;
```

```tablegen
def GPR : RegisterClass<"J2", [ i32 ], 32, (add R0, [...], R15)>;
```

Reserved registers

---

## Tablegen

#### Why ?

##### Avoid duplication

##### Avoid C++ metaprogramming

##### Easily modulable

##### Focus on the description of the target

---

# Instructions

## Instruction formats

```tablegen
class FNM<bits<4> op, bits<4> data, dag outs, dag ins, string asmstr,
          list<dag> pattern> {

bits<4> dst;
    bits<4> src;

let Inst{15 - 12} = op;
    let Inst{11 - 8} = dst;
    let Inst{7 - 4} = src;
    let Inst{3 - 0} = data;
}
```

---

## my_first_instruction

```center
add r0, r14
```

#### RTFM

```center
add Rm,Rn                        Rm + Rn -> Rn                    0011nnnnmmmm1100
```

---

```center
add Rm,Rn                        Rm + Rn -> Rn                    0011nnnnmmmm1100
```

```tablegen
let                 ,                            ,           in {
  def ADDrr :    <   ,    , (outs         ), (ins                  ),
                  "             ",
                  [ (                                     ) ]>;
```

---

```center
add Rm,Rn                        Rm + Rn -> Rn                    0011nnnnmmmm1100
```

```tablegen
let                 , Constraints = "$rnd = $rns",           in {
  def ADDrr :    <   ,    , (outs GPR:$rnd), (ins GPR:$rm, GPR:$rns),
                  "             ",
                  [ (                                     ) ]>;
```

---

```center
add Rm,Rn                        Rm + Rn -> Rn                    0011nnnnmmmm1100
```

```tablegen
let                 , Constraints = "$rnd = $rns",           in {
  def ADDrr :    <   ,    , (outs GPR:$rnd), (ins GPR:$rm, GPR:$rns),
                  "             ",
                  [ (set i32:$rnd, (add i32:$rm, i32:$rns)) ]>;
```

---

```center
add Rm,Rn                        Rm + Rn -> Rn                    0011nnnnmmmm1100
```

```tablegen
let                 , Constraints = "$rnd = $rns",           in {
  def ADDrr :    <   ,    , (outs GPR:$rnd), (ins GPR:$rm, GPR:$rns),
                  "add $rm, $rnd",
                  [ (set i32:$rnd, (add i32:$rm, i32:$rns)) ]>;
```

---

```center
add Rm,Rn                        Rm + Rn -> Rn                    0011nnnnmmmm1100
```

```tablegen
let                 , Constraints = "$rnd = $rns",           in {
  def ADDrr : FNM<0x3, 0xC, (outs GPR:$rnd), (ins GPR:$rm, GPR:$rns),
                  "add $rm, $rnd",
                  [ (set i32:$rnd, (add i32:$rm, i32:$rns)) ]>;
```
---

```center
add Rm,Rn                        Rm + Rn -> Rn                    0011nnnnmmmm1100
```

```tablegen
let isCommutable = 1, Constraints = "$rnd = $rns", isAdd = 1 in {
  def ADDrr : FNM<0x3, 0xC, (outs GPR:$rnd), (ins GPR:$rm, GPR:$rns),
                  "add $rm, $rnd",
                  [ (set i32:$rnd, (add i32:$rm, i32:$rns)) ]>;
```

---

### What is actually generated

##### J2GenAsmMatcher.inc - AsmParser

```c++
static const MatchEntry MatchTable0[] = {
  { 0 /*add*/, J2::ADDrr, Convert_Reg1_1_Reg1_0_Tie0, 0, { MCK_GPR, MCK_GPR }, },
```

##### J2GenAsmWriter.inc - AsmPrinter

```c++
case 2:
  // ADDrr
  printOperand(MI, 1, O);
  O << ", ";
  printOperand(MI, 0, O);
  return;
  break;
```

---

### What is actually generated

##### J2GenDisassemblerTables.inc - Disassembler

```c++
static const uint8_t DecoderTable16[] = {
  /* 221 */     MCD::OPC_Decode, 83, 4, // Opcode: ADDrr
```

##### J2GenMCCodeEmitter.inc - Assembler

```c++
case J2::ADDrr:
  // op: src
  op = getMachineOpValue(MI, MI.getOperand(0), Fixups, STI);
  Value |= (op & UINT64_C(15)) << 4;
  // op: dst
  op = getMachineOpValue(MI, MI.getOperand(1), Fixups, STI);
  Value |= (op & UINT64_C(15)) << 8;
  break;
```

---

### What is actually generated

##### J2GenDAGISel.inc - Instruction selection

```c++
static const unsigned char MatcherTable[] = {
/*670*/         OPC_MorphNodeTo1, TARGET_VAL(J2::ADDrr), 0,
                    MVT::i32, 2/*#Ops*/, 0, 1,
                // Src: (add:i32 i32:i32:$rm, i32:i32:$rns) - Complexity = 3
                // Dst: (ADDrr:i32 i32:i32:$rm, i32:i32:$rns)
/*678*/       0, /*End of Scope*/
```

##### J2GenInstrInfo.inc - Instruction information

```c++
namespace J2 {
  enum {
    ANDrr = 83,
```

```c++
  { 83, 3,  1,  2,  0,  0|(1ULL<<MCID::Add)|(1ULL<<MCID::Commutable), 0x0ULL,
    nullptr, nullptr, OperandInfo22, -1 ,nullptr },  // Inst #83 = ADDrr
```

---

# Code generation

---

# Code generation

### Legalization

```llvm
%sh = shl r1, 20
```
```asm
shll16 r1
shll2 r1
shll2 r1
```

```c++
setOperationAction(SHL, i32, Custom);
```

Then lower manually.

---

# Code generation

### Legalization

Legal

* Supported by the target.

Libcall

* Call the runtime.

Promote

* Promote the type to a larger type.

Expand

* Expand to other opereations, if possible.

---

# Code generation

### Instruction Selection

##### IR -> DAG

#### Convert IR to a graph (DAG)

##### BB -> MBB

#### Select one basic block at a time

##### Select()

#### Generic algorithm, based on the generated files from every target

##### Custom

#### But some manual work needs to be done

---

# Code generation

### Instruction Selection

##### Addressing modes

```c
int tab[30];
int a = tab[2];
```

```asm
mov.l @Rm, Rn                           -                   (Rm) -> Rn
mov.l @(R0, Rm), Rn                     -                   (R0 + Rm) -> Rn
mov.l @(disp, Rm), Rn                   -                   (Rm + disp * 4) -> Rn
```

Select the correct addressing mode.

```asm
mov.l @(2, r14), r1
```

---

# Code generation

### Frame lowering

##### Prologue / Epilogue

```asm
mov.l r14, @r15			 ; push $fp
mov r15, r14				; $fp = $sp
add #-8, r15				; $sp -= 8
[...]
mov r14, r15				; $sp = $fp
mov.l @14, r14			  ; pop $fp
rts						 ; return
```

##### Callee save / regalloc spilling

* storeRegToStackSlot

* loadRegFromStackSlot

---

# LLD

## ELF, COFF, Mach-O

### New design

### C++

### lld == 13k lines ; gold == 146k lines

### 1.2x to 2x faster than gold

---
class: middle, center, inverse

# What we don't need to do

### Generate sections

### Merge sections

### Generate output file

### Everything except relocations

---
class: top, center, inverse

# LLD

### Relocations - the other side

```c++
void relocateOne(uint8_t *Loc, uint32_t Type, uint64_t Val) const;
```

* Machine code in `Loc`

* Relocation type in `Type`: R_J2_BSR, R_J2_BRA, etc.

* The value to be written in `Val`: 0x2, 0x403430, etc.

---
class: middle, center, inverse

# Relocations
## the other side

### J2 calls

```asm
bsr label
```
```
PC + 4 -> PR
disp * 2 + PC + 4 -> PC (Delayed branch)
```
```
1011dddddddddddd
```

* J2 calls are PC-relative

* +/- 4096

---
class: middle, center, inverse

# Relocations
## the other side

### J2 calls

```asm
jsr @Rm
```
```
PC + 4 -> PR
Rm -> PC (Delayed branch)
```
```
0100mmmm00001011
```

* Indirect call

* 32bit absolute address

---
class: top, center, inverse

# Relocations
## the other side

### 4 x immediate mov

Jump to 0x134:

```objdump
*10e:	00 e0 	mov	  #0, r0                ; 0b0
110:	18 40 	shll8	r0                    ; 0b0
*112:	00 cb 	or	   #0, r0                ; 0b0
114:	18 40 	shll8	r0                    ; 0b0
*116:	01 cb 	or	   #1, r0                ; 0b1
118:	18 40 	shll8	r0                    ; 0b100000000
*11a:	34 cb 	or	   #52, r0A              ; 0b100110100
[...]
122:	0b 40 	jsr	  @r0
124:	09 00 	nop
```

* 4 x 1B relocations

---
class: top, center, inverse

# Relocations
## the other side

### PC-relative mov

```asm
mov.l @(disp,PC),Rn
```
```
(disp * 4 + (PC & 0xFFFFFFFC) + 4) -> Rn
```
```
1101nnnndddddddd
```

* PC-relative load

* Can use this + JSR to call an absolute 32-bit address

---
class: top, center, inverse

# Relocations
## the other side

### 1 x immediate mov

Jump to 0x134:

```objdump
10c:	05 d0	mov.l @(5, PC), r0
*10e:	0b 41	jsr	@r0
110:	09 00	nop
[...]
11c:	0b 00	rts
11e:	09 00	nop
120:	34 01	.data.l 0x134
```

* Add data at the end of the function

* Load PC-relative data into register

---

# TODO

### tests, more tests, even more tests, qemu, fpga, exception handling, selectcc, plt, got, default linker script, clang intrinsics, undef, debug info, mul, div, not, 64bit op, fp, vectorization, frame pointer elimination, subtargets, delay slot filling, global variables, constant pools, inline asm, atomics, alloca, byval, varargs, jit, tls, relaxation, scheduling, branch folding, runtime, loader, .data, .bss, tail call, etc.

---
class: middle, center, inverse

#### References

http://llvm.org/docs/WritingAnLLVMBackend.html

http://www.shared-ptr.com/sh_insns.html
]

## Any questions?

##### <francis@lse.epita.fr>

---
class: middle, center, inverse

### xtrct

#### WHY ???????????????????????

```
xtrct Rm,Rn                 Rm:Rn middle 32 bits -> Rn            0010nnnnmmmm1101
```
